Aluminum XMZD75 Folding Door Series

  • Opening Style: Opening inwards, Casement
  • Alloy & Temper: Aluminum 6063-T5
  • Size: As per drawing
  • Surface Treatment: Powder coated, Electrophoretic coated, PVDF coated, wood transfer
  • Quality Standard & Certification: GB/T5237-2017, AAMA, CQM, Qualicoat, SEASIDE
  • Class Option: Double glazed: 5-9 (or 12)-5mm
  • Low-E: Tinted/frosted/obscure
  • Hardware: CMECH, KIN LONG, Roto, SIEGENIA
  • Payment Term: T/T (30% advance payment/deposit by T/T, and 70% paid against copy of B/L afters)
  • Delivery Terms: FOB, EXW

2F63136-J

2F79980-J

2F303234-J

2F402522

5609PU614

5721M676A

5720M660

5722MJ219

101C

402CJ

9107445

9016

Aluminum XMZD75 Folding Door Series Assembly Structure

Aluminum XMZD75 Folding Door Series Assembly Structure

Profile Processing Cutting

Profile Processing Cutting

45 Degrees Angle Cutting

45 Degrees Angle Cutting

End Face Milling of Middle Column

End Face Milling of Middle Column

Profile Lock Body Corner Connector Punching

Profile Lock Body Corner Connector Punching

Open Screw Holes for Hardware Fittings

Open Screw Holes for Hardware Fittings

Cutting Corner Connector

Cutting Corner Connector

45 Degrees Profile Impact Corner Connector

45 Degrees Profile Impact Corner Connector

Doors and Windows Assembly

Doors and Windows Assembly

Stick Protective Film

Stick Protective Film

Install Glass Glue

Install Glass Glue

Door and Window Installation and Debugging

Door and Window Installation and Debugging

Finished Product Debugging

Finished Product Debugging

Check the Size

Check the Size

The Finished Product Delivery

The Finished Product Delivery


Casement Door Lock Body

Casement Door Handle Component

Hinge

Lock Bracket

Lock Cylinder

Features

The alloy aluminium folding sliding door adopts upper and lower supporting structure to have better bearing quality. Used with high strength stainless steel slide rail, more stable and smooth.The innovative hinged hiding structure provides better impervious performance, allowing the hinge to be hidden when closed, and the entire aluminium folding sliding door looks more elegant.The hidden structure of hinge is located inside the aluminium profile to avoid the deformation of window sash when opened or stressed. It's easier to install and distributes pressure evenly.Special rubber seal structure ensures better air and water tightness. Customized open mode, such as 440, 422, 431, 321, etc., can realize full angle open mode and provide a broader vision.The magnificent and elegant appearance is suitable for villas, hotel lobbies and exhibition centres, etc.

Performance

Air Classification Class 6 (m³/m•h)

Water Tightness Class 4: 450 Pa

Wind Resistance Class 4: 2.5 kPa

Soundproof Class 4: 35 dB

Thermal Transmittance Uf Class 4: 3.0w/(㎡•k)

Aluminium folding sliding doors are the ideal solution for conservatories and other large glass expanses with an irregular opening such as those found in bathrooms, kitchens and conservatories. The added benefit of these doors being able to slide open is that they offer more space and allow better ventilation for dry climates. If you wish to buy them, you should bear in mind a few factors before you purchase them. They are ideal if you wish to save on the cost of heating your conservatory or if you want the best value for money on your cooling bill, or even both.

These days, the market place for aluminium folding sliding doors is flooded with many options. Many companies offer bi-folding and even triple glazed ones with additional features such as rain and wind guards, security features, UPVC windows and so forth. All offer different benefits and some can be expensive. If you want to make sure that you get a good deal, you should choose a door that incorporates a high performance glazing system. It's essential that it not only provides good insulation and ventilation but it also has the required strength to withstand the stresses of frequent opening and closing. There are several advantages of using high performance glazing panels such as being able to provide higher levels of energy efficiency, increased security and enhanced aesthetics.

The kind of glazing used on aluminium folding sliding doors can have a big impact on the strength of the door. The better the quality of the panels the higher the level of protection it offers against all kinds of forces and weather conditions, including the kind that can cause a door to become warped when it is being poorly maintained. Some manufacturers use special resins to increase the lifetime of the panels even when no heat is applied to the frames. However, they are not a substitute for regular lubrication and inspection.

In order to ensure optimum performance from your aluminium folding sliding doors, regular cleaning, lubrication and inspection should take place. When you are buying these doors, look for a company that offers you a comprehensive service and after sales service and technical specifications assistance as well. Make sure you take the time to fully understand the technical specifications included in each individual panel. This way, you can make sure you are purchasing the best materials available and you get your money's worth.

Another great reason why aluminium folding sliding doors offer a range of benefits is because they have a natural beauty that can enhance any home. Your property can become more appealing by simply selecting beautiful bold or timber framed panels for the exterior of your home. You will soon see the difference that a timber frame can make to your property and the investment you make will be one that pays for itself over time.
